PVC Material: Copper, PVC
Operating voltage: 600V
Temperature withstand: 75℃
Surface treatment of brass parts: tin coating
| spec(mm²) | 1.25 | 2 | 5.5 |
| Max current(A) | 19 | 27 | 48 |
| Cable Size | ITEM NO. | Size (mm) | Color | pcs/pack | ||||||
| d2 | B | F | L | H | D | T | ||||
| A.W.G. 22-16 0.5-1.5mm2 | DSVE1.25-3 | 3.2 | 5.5 | 6.5 | 22 | 11 | 4 | 0.75 | red | 1000 |
| DSVE1.25-3.5S | 3.7 | 5.5 | 1000 | |||||||
| DSVE1.25-3.5L | 3.7 | 6.5 | 1000 | |||||||
| DSVE1.25-4S | 4.3 | 6.5 | 1000 | |||||||
| DSVE1.25-4M | 4.3 | 7 | 1000 | |||||||
| DSVE1.25-4L | 4.3 | 8 | 1000 | |||||||
| DSVE1.25-5S | 5.3 | 8 | 1000 | |||||||
| DSVE1.25-5L | 5.3 | 9.5 | 1000 | |||||||
| DSVE1.25-6S | 6.4 | 9.5 | 1000 | |||||||
| DSVE1.25-6L | 6.4 | 12 | 11 | 28 | 1000 | |||||
| A.W.G. 16-14 1.5 ~ 2.5mm2 | DSVE2-3 | 3.2 | 5.5 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | blue | 1000 |
| DSVE2.-3.5S | 3.7 | 5.5 | 1000 | |||||||
| DSVE2-3.5L | 3.7 | 7 | 1000 | |||||||
| DSVE2-4S | 4.3 | 6.5 | 1000 | |||||||
| DSVE2-4M | 4.3 | 7 | 1000 | |||||||
| DSVE2-4L | 4.3 | 8 | 1000 | |||||||
| DSVE2-5S | 5.3 | 8 | 1000 | |||||||
| DSVE2-5L | 5.3 | 9.5 | 1000 | |||||||
| DSVE2-6S | 6.4 | 9.5 | 1000 | |||||||
| DSVE2-6L | 6.4 | 12 | 11 | 28.5 | 1 | yellow | 1000 | |||
| A.W.G. 12-10 4 ~ 6mm2 | DSVE5.5-3.5 | 3.7 | 8.5 | 7.5 | 26.5 | 14 | 6.5 | 1000 | ||
| DSVE5.5-4S | 4.3 | 8.5 | 1000 | |||||||
| DSVE5.5-4L | 4.3 | 9.5 | 1000 | |||||||
| DSVE5.5-5 | 5.3 | 9 | 1000 | |||||||
| DSVES5.5-6 | 6.4 | 9 | 1000 | |||||||
| DSVE5.5-6L | 6.4 | 12 | 12 | 32.5 | 500 | |||||
| DSVE5.5-8L | 8.4 | 14 | 11.5 | 31.5 | 500 | |||||
