Material: Copper，PVC
Operating voltage: 600V
Temperature withstand: 75℃
Surface treatment of brass parts: tin coating
| spec(mm²) | 1.25 | 2 | 5.5 |
| Max current(A) | 19 | 27 | 48 |
| Cable Size | ITEM NO. | Size (mm) | Color | pcs/pack | ||||||||
| d2 | d3 | B | L | F | H | D | d1 | T | ||||
| A.W.G. 22-16 0.5~1.5mm2 | DMSRV1.25-2237 | 3.7 | 2.2 | 7 | 22 | 7 | 10 | 4.5 | 2 | 0.75 | red | 1000 |
| DMSRV1.25-3753 | 5.3 | 3.7 | 8.5 | 24.5 | 8 | 1000 | ||||||
| A.W.G. 16-14 1.5~2.5mm2 | DMSRV2-2237 | 3.7 | 2.2 | 7 | 22 | 7 | 10 | 5 | 2.5 | 0.8 | blue | 1000 |
| DMSRV2-3753 | 5.3 | 3.7 | 8.5 | 24.5 | 8 | 1000 | ||||||
| A.W.G. 12-10 4~6mm2 | DMSRV5.5-3753 | 5.3 | 3.7 | 10 | 28.5 | 9 | 13 | 6.5 | 3.5 | 0.1 | yellow | 1000 |
