Product Parameter
Brand: cnsdi
Product or component type:Comb busbar
Mounting mode:Horizontal
Part code: CDi-pin1.4x7x4-1P 24W 63/18mm
Amperage Rating    :63 A
Material: t3Copper and Pvc
Accessory / separate part category:Connection accessory
Lines description:1L
Length in 18 mm modules:24
Standards:IEC 60898-1,IEC 60947-7-1
Color:  White

This CDi-pin147 product is a cuttable horizontal comb busbar 24 modules for UL 489 listed miniature circuit breakers up to a 63 A current rating. It is dedicated to 1L installations. The type is L (Line). It is a set of 1 device. It is suitable for 24 devices (1P). The length is 435mm.The total number of modules of 18mm is 24. The pin cross section is 10mm2. The type of electric connection is PIN. The Ui rated insulation voltage is 500VAC. The Ue rated operational voltage is 500VAC.The color of the device is white. It complies with IEC 60947-7-1 and IEC 60898-1 standards.

ZHEJIANG SUODI ELECTRIC CO., LTD. is a professional manufacturer,specializing in electrical accessories products.
cnsdi has 20 years of design and production experiences, complete product categories and serves many companies.
